Rega ELICIT MK5

    £2,000.00
    Tax included. Shipping calculated at checkout.
    DESCRIPTION +

    Rega ELICIT MK5

    The all new Elicit MK5 stereo integrated amplifier is designed and built to the highest standard. Housed in our latest custom case to match the rest of the Rega range, the new MK5 builds on previous Rega designs by using our multi-award-winning Class A/B power amplifier circuit to deliver a powerful 105 W per channel into 8 Ω loads (127 W into 6 Ω). Our engineers have taken great care to incorporate a high-quality MM phono stage, the headphone input socket has been integrated such that the speaker switching is performed by the output mute relay so as not to obstruct the signal path. Our engineers have incorporated a new design Rega DAC offering digital connectivity and greater flexibility with a variety of other products.



    The Elicit MK5 now shares other design features taken directly from the highly acclaimed Aethos amplifier. You will find the same discrete FET based pre-amplifier circuit, plus an Alps volume potentiometer has been introduced to further improve sonic and technical performance. As you would expect, special attention has been paid to the selection of key audio components. Discrete circuitry, high-quality relays, polypropylene capacitors, and Sanken output transistors are used throughout the design.



    Key features:



    • 105 W per channel into 8 Ω
    • High quality moving magnet phono stage
    • 2 x Digital inputs - 1 x optical and 1 x Co-Axial
    • High performance Rega DAC circuit for digital inputs
    • 4 Line level inputs
    • Headphone input
    • Direct Input
    • Record input
    • New advanced pre-amplifier
    • Alps volume potentiometer
    • Thermal Cut-Out


    The Elicit MK5 now shares other design features taken directly from the highly acclaimed Aethos amplifier. You will find the same discrete FET based pre-amplifier circuit, plus an Alps volume potentiometer has been introduced to further improve sonic and technical performance. As you would expect, special attention has been paid to the selection of key audio components. Discrete circuitry, high-quality relays, polypropylene capacitors, and Sanken output transistors are used throughout the design.

    The galvanically/optically isolated digital inputs utilise a Wolfson S/PDIF receiver IC to provide exceptional detail and clarity from any connected source. Output is provided by a Wolfson DAC and Rega designed discrete line-driver circuit. The new Elicit MK5 calls upon decades of award-winning experience in amplifier and digital circuit design which culminates in a perfectly engineered balance of reliability, connectivity and above all, accurate music reproduction.





    SPECIFICATION +

    Power Output

    • 105 Watts per channel into 8
    • 127 Watts per channel into 6
    • 162 Watts per channel into 4
    • Input sensitivity for 105 Watts into 8
    • Line inputs (input 1 switch set to line) 1-5 and record - 196mV load 10K
    • Phono (input 1 switch set to phono) - 2mV Load 47K in parallel with 220pF
    • Direct input - 760mV Load 50K
    • Power amplifier gain - 31.6dB
    • Record output - 196mV for rated inputs
    • Pre-amplifier output - 760mV for rated inputs
    • Dimensions: W 432mm x D 325mm x H 82mm
    • Weight - 13kg
