    Meridian DSP7200SE Special Edition

    £30,000.00
    Tax included. Shipping calculated at checkout.
    DESCRIPTION +



    The Special Edition DSP7200 demonstrates the ultimate expression of high-resolution audio that can be achieved within a loudspeaker of its size.

    The DSP7200SE’s additional DSP processor and drive-unit clamp rings, combined with extreme cabinet resonance control, guarantee the listener hears the finest details. Its beryllium tweeter delivers breathtaking clarity and detail that can be enjoyed effortlessly for long periods of time. This optimum fidelity is supported by punch and control, making the DSP7200SE the perfect solution for authentic audio in small to medium-sized rooms (20-50m2).

    The additional DSP device, used by the Special Edition loudspeakers, doubles the available processing power allowing all audio, including MQA Core streams, to be rendered at 176.4/192kHz regardless of the incoming sampling rate. This results in increased resolution, detail, and clarity to provide maximum fidelity from music and movies.

    FEATURES +

    Meridium

    Loudspeaker enclosures often vibrate, colouring the sound, making it less lifelike. Our most advanced loudspeakers use a cabinet construction material unique to Meridian: Meridium features highest-grade laminated plywood layers bonded to an aluminium core, allowing the loudspeaker to reproduce music accurately without adding its own sound.

    Speaker Link

    Traditional audio systems often require large, expensive cables to maintain their performance. Meridian's SpeakerLink uses an “Ethernet style” cable that delivers pristine digital sound and control down a single cable between Meridian components. The result is simple, unobtrusive, and cost-effective cables that are easy to install<

    Fifo Buffering

    Digital Signal Processing

    As pioneers and leaders in the field of Digital Signal Processing (DSP) technology, Meridian is able to deliver your music authentically to recreate the passion and involvement of your musical moments. Power-efficient, active DSP crossovers are individually tailored to distribute music to each speaker, bringing your music to life.

    DSP Loudspeakers

    The traditional setup – amplifiers driving passive loudspeakers – is inefficient, limiting sound quality. Meridian loudspeakers contain a complete, matched audio system with efficient DSP crossovers, multiple DACs and driver-specific amplifiers, giving higher overall quality, less power use, and the performance of a traditional loudspeaker eight times the physical volume.

    SPECIFICATION +

    AUDIO INPUTS
    Meridian SpeakerLink (RJ45) & RCA phono digital inputs accepting 32kHz to 96kHz sampling rates at up to 24-bit, with MHR support

    AUDIO OUTPUTS
    Meridian SpeakerLink (RJ45) & RCA phono digital outputs delivering 32kHz to 96kHz sampling rates at up to 24-bit, with MHR support

    PERFORMANCE
    Peak SPL: 118dB at 1m (music material)

    Noise less than 15dB SPL

    Frequency response in-room within 3dB: 30Hz to over 32kHz

    AMPLIFIERS
    4 x 150W (600W)

    Overall distortion typically <0.02% at any frequency or level

    BASS DRIVERS
    2 x 200mm polypropylene long-throw

    MID DRIVER
    160mm polypropylene

    BERYLLIUM DOME TWEETER
    25mm (1”) Meridian piston in short-horn, beryllium dome with silver voice-coil.

    DSP FEATURES
    2 x Freescale 56367 running at 150MH

    FIFO memory buffer input for the lowest possible jitter from almost any source

    Linear-phase mid–top crossover; 6th-order Linkwitz-Riley bass–mid crossover

    Bass protection

    Response correction for the whole loudspeaker

    Hybrid analogue/digital volume control

    Balance control with proportional delay compensation

    DISPLAY
    Eight-character display with additional status indicators; can be blanked in use

    DIMENSIONS / WEIGHT
    HEIGHT; 1072mm [42.2in] (Without feet/spikes)

    WIDTH: 178mm [7in] tapering to 350mm [13.8in]

    DEPTH: 220mm [8.7in] tapering to 422mm [16.6in]

    FOOTPRINT (W x D): 350mm [13.8in] x 422mm [16.6in]

    WEIGHT: 55kg [121lbs]

    POWER
    20VA standby; 600
