ARCAM Radia AVA35 AV Amplifier - 9-Channel Class G Integrated Cinema Amplifier

Key Features

• Nine channels of ARCAM Class G amplification delivering 100W per channel into 8Ω (all channels driven)
• Signature Class G technology unique to ARCAM for superior power, lower crossover distortion, and unmatched musicality
• Complete immersive audio decoding: Dolby Atmos, DTS:X, IMAX Enhanced, and Auro-3D processing
• Matrix Channel Assignment across all 16 channels for ultimate configuration flexibility
• Dirac Live room correction tailored to your listening environment
• High-performance DAC architecture from ARCAM's flagship stereo systems
• Comprehensive streaming integration: Apple AirPlay, Google Cast, Spotify Connect, Tidal Connect, Qobuz Connect, and Roon Ready

The Summit of Home Cinema and Musical Performance

For those who refuse to compromise, the ARCAM Radia AVA35 represents the summit of home cinema and musical performance. This is not just an amplifier—it's ARCAM's most advanced integrated AV solution, designed for true connoisseurs of sound. Expertly engineered in Cambridge, UK, the AVA35 harnesses ARCAM's signature Class G amplification, a technology unique to the brand and revered for its ability to deliver superior power, lower crossover distortion, and unmatched musicality.

Reserve yours today and experience the pinnacle of integrated AV amplification.

Revolutionary Class G Amplification Technology

At the heart of the AVA35 lies ARCAM's proprietary Class G amplification technology—a design philosophy that sets this integrated amplifier apart from conventional AV receivers. Class G amplification delivers exceptional efficiency by switching between multiple power supply rails according to the signal's demands, providing the power reserves needed for dynamic cinema soundtracks whilst maintaining the delicacy and detail that music reproduction demands.

With nine channels delivering 100W into 8Ω (all channels driven) or 150W into 4Ω, the AVA35 provides substantial power reserves for even demanding loudspeaker systems. When driving two channels, output increases to 125W into 8Ω or 220W into 4Ω, ensuring dynamic headroom for the most challenging passages. Harmonic distortion measures just 0.002% at 80% power into 8Ω at 1kHz—a testament to ARCAM's obsession with audio purity.

Flagship DAC Architecture for Uncompromising Sound Quality

Combined with the same high-performance DAC architecture found in ARCAM's flagship stereo systems, the AVA35 ensures every note and every cinematic moment is rendered with breathtaking clarity and emotional impact. The frequency response extends from 20Hz to 20kHz with a tolerance of just ±0.05dB, whilst the signal-to-noise ratio of 100dB (A-weighted) guarantees a silent background from which even the subtlest details emerge.

At ARCAM, sound quality isn't just a promise—it's an obsession. The AVA35 represents the pinnacle of rigorous testing and critical listening sessions, more than deserving of the ARCAM name. This commitment to sonic excellence means the AVA35 excels equally with orchestral scores, intimate jazz recordings, and explosive cinema soundtracks.

Complete Configuration Flexibility

For the ultimate in flexibility, the AVA35 introduces matrix channel assignment, allowing you to reallocate channels freely for the most personalised and immersive configurations. Whether it's music, movies, gaming, or sport, this amplifier adapts to your vision of perfection. All 16 channels can be reassigned (with subwoofers routable to channels 4 and 11-16), providing unprecedented control over your system architecture.

With nine channels of Class G power, Dolby Atmos, DTS:X, IMAX Enhanced, and Auro-3D processing, combined with Dirac Live room correction, the AVA35 transforms your space into a world-class listening environment. The processor supports Dolby Atmos Height Virtualisation and DTS Virtual:X for enhanced immersion even without dedicated height speakers, whilst Dolby Surround and DTS Neural:X upmixing breathe new life into legacy content.

Cutting-Edge HDMI and Video Processing

The AVA35 is comprehensively equipped for today's 8K displays and tomorrow's requirements. Seven HDMI 2.1a inputs and dual outputs (plus an additional output for Zone 2) support resolution up to 8K/60Hz or 4K/120Hz. Advanced features include Variable Refresh Rate (VRR) and Auto Low Latency Mode (ALLM) for responsive gaming performance, whilst support for HDR, HDR10, HDR10+ Gaming, Dolby Vision, and HLG ensures stunning picture quality from any compatible source.

Enhanced Audio Return Channel (eARC) on Zone 1 Output 1 provides seamless integration with smart televisions, allowing high-resolution audio formats to pass from your television's streaming apps directly to the AVA35. On-screen display facilitates straightforward setup and source selection, whilst CEC control integration creates a unified entertainment system.

Comprehensive Digital and Analogue Connectivity

Beyond HDMI, the AVA35 offers extensive connectivity for all sources. Two coaxial digital inputs support sample rates up to 192kHz at 24-bit resolution, whilst dual optical inputs handle signals up to 96kHz. Three pairs of analogue RCA inputs provide connectivity for turntables (via external phono stage), tape decks, or other line-level sources. All inputs maintain ARCAM's exacting standards: frequency response of 20Hz–20kHz ±0.2dB and signal-to-noise ratio of 100dB.

Sixteen RCA preamplifier outputs (2V RMS peak per channel) allow connection to external power amplifiers for expanded system configurations, with THD+N measuring –100dB across the 20Hz–20kHz bandwidth. This flexibility ensures the AVA35 can anchor both compact nine-channel systems and expansive multi-amplifier installations.

Seamless Streaming Integration

Modern connectivity meets traditional hi-fi excellence. The AVA35 works seamlessly with the new ARCAM Radia app for setup, control, internet radio, and podcasts. Streaming services integrate directly through Spotify Connect, Tidal Connect, and Qobuz Connect, whilst Apple AirPlay and Google Cast provide additional wireless streaming options. Roon Ready certification ensures bit-perfect playback from Roon-managed music libraries.

The amplifier supports comprehensive high-resolution file formats including FLAC, WAV, MQA, ALAC, AIFF, and DSD up to DSD128, with sample rates reaching 192kHz and 24-bit depth. Gapless playback ensures seamless transitions between tracks, whilst the streaming pathway maintains a frequency response of 20Hz–20kHz ±0.05dB—matching the performance of direct digital inputs.

Bluetooth 5.4 with Snapdragon Sound and Auracast ensures high-quality wireless audio transmission, supporting AAC, LE Audio, and multiple connection profiles for flexible wireless connectivity.

Intuitive Control and Display

Control is effortless—because the experience should be as seamless as the sound. The vibrant 6.5-inch high-resolution colour display presents status information and metadata with exceptional clarity, clearly visible from the comfort of your main listening position. The Bluetooth remote control allows continuous operation even when the amplifier is out of sight, whilst the ARCAM Radia app provides comprehensive setup and control from your mobile device.

Intuitive menus guide you through complex system configuration, making professional-level room correction and channel assignment accessible to any enthusiast. The interface balances sophistication with usability, ensuring that accessing the AVA35's extensive capabilities never becomes a barrier to enjoyment.

Cambridge Engineering Heritage

ARCAM's reputation for audio excellence stems from decades of British engineering expertise. Manufactured by Harman International in Cambridge, UK, the AVA35 benefits from the same rigorous engineering standards and attention to detail that have made ARCAM a benchmark in high-fidelity audio reproduction. The unique Class G amplification topology represents years of development and refinement, delivering performance that conventional Class AB or Class D designs cannot match.

This commitment to quality extends to environmental responsibility, with plastic-free packaging reflecting ARCAM's dedication to sustainable manufacturing practices.

Expert Recognition

"The pinnacle of home cinema processing and amplification. For those who demand nothing less than perfection." — ARCAM Engineering Team

The AVA35 represents decades of ARCAM's amplifier design expertise, combining unprecedented flexibility with the audio quality audiophiles expect from this prestigious British manufacturer.

Technical Specifications

Amplification:

• Channels: 9, Class G topology
• Continuous power output (0.5% THD):
  • 125W per channel into 8Ω (2 channels driven, 20Hz–20kHz)
  • 220W per channel into 4Ω (2 channels driven, 1kHz)
  • 100W per channel into 8Ω (all 9 channels driven, 20Hz–20kHz)
  • 150W per channel into 4Ω (1kHz)
• Harmonic distortion: 0.002% at 80% power, 8Ω, 1kHz

Audio Processing:

• Maximum channel count: 16 (all channels reassignable; subwoofers into CH4/11-16 only)
• Decoding formats: Dolby Atmos, Dolby TrueHD, DTS:X, DTS HD Master, IMAX Enhanced, Auro-3D, MPEG-H
• Virtual height processing: Dolby Atmos Height Virtualisation, DTS Virtual:X
• Upmixing: Dolby Surround, DTS Neural:X
• Room correction: Dirac Live
• Frequency response: 20Hz–20kHz ±0.05dB

Digital Inputs:

• Coaxial: 2x RCA (up to 192kHz, 24-bit)
• Optical: 2x Toslink (up to 96kHz, 24-bit)
• Frequency response: 20Hz–20kHz ±0.2dB
• Signal-to-noise ratio: 100dB (A-weighted)

Analogue Inputs:

• 3x RCA stereo pairs
• Signal-to-noise ratio: 100dB (A-weighted, reference 1V input)
• Frequency response: 20Hz–20kHz ±0.2dB

Preamplifier Outputs:

• 16x single-ended RCA outputs (2V RMS peak per channel)
• THD+N (20Hz–20kHz): –100dB

HDMI Connectivity:

• Inputs: 7x HDMI 2.1a (HDCP 2.3)
• Outputs: 2x (Zone 1), 1x (Zone 2)
• Maximum resolution: 8K/60Hz or 4K/120Hz
• HDR formats: HDR10, HDR10+, HDR10+ Gaming, Dolby Vision, HLG
• Gaming features: VRR, ALLM
• eARC/ARC support (Zone 1, Output 1)
• On-screen display: Yes

Streaming Services:

• Apple AirPlay, Google Cast
• Spotify Connect, Tidal Connect, Qobuz Connect
• Roon Ready
• Internet radio and podcasts via ARCAM Radia app
• UPnP network playback

Supported File Formats:

• Hi-res audio: FLAC, WAV (LPCM), MQA, ALAC, AIFF, DSD (up to DSD128)
• Standard formats: AAC, MP3, OGG, WMA
• Sample rates: Up to 192kHz
• Bit depths: 16-bit, 24-bit
• Gapless playback supported
• Streaming frequency response: 20Hz–20kHz ±0.05dB

Wireless Connectivity:

• Bluetooth 5.4 (A2DP Sink/Source, AVRCP)
• Snapdragon Sound, AAC, LE Audio, Auracast

Physical Specifications:

• Dimensions (W×D×H): 432 × 459.1 × 170mm
• Weight: 22.7kg (net), 29.4kg (packed)
• Power consumption: 900W maximum
• Mains voltage: 100-120V/220-240V, 50/60Hz
• Packaging: Plastic-free

ARCAM's Most Advanced Integrated AV Solution

The ARCAM Radia AVA35 stands as the pinnacle of integrated home cinema amplification. With nine channels of proprietary Class G amplification, comprehensive immersive audio decoding, flagship DAC architecture, and the complete flexibility of matrix channel assignment, the AVA35 delivers a truly world-class experience for those who refuse to compromise.

Experience the summit of home cinema and musical performance. Reserve your ARCAM Radia AVA35 today.
