Vitus SM-011 Monoaural Power Amplifier

These incredible pure class A/AB mono amps share a chassis size with it’s sibling the SS-025 Mk.II. Based on the technical leaps made with the original SIA-025, the SM-011 uses SMD in place of leaded components wherever possible, fitting an incredible amount of technology in a modest space.

The completely modular Vitus Audio design means future upgradability is a given and in this version we introduced two different modes of coupling the output as developed for the MP-S201.

The SM-011 builds on the success of the SIA-025. You get more of everything, more silence, higher resolution, more power and better dynamics. The amps feature a 1.4kVA custom UI transformer with <2% loss, a 240.000µF capacitor bank, is true balanced from input to output and as always, there is zero global negative feedback. This is a magnificent amplifier that will offer incredible performance for a lifetime.

The SM-011 comes in Pure White, Jet Black or Warm Silver as standard. Titanium Orange, Dark Champagne and Titanium Grey are our most popular unique finishes.

TECHNICAL SPECS

INPUT (EACH) XLR ANALOGUE      RCA ANALOGUE
Available 1                                         1
Sensitivity 2 VRMS                             2 VRMS
Impedance 10kΩ                               10kΩ

OUTPUT (EACH CH.)                          SPEAKERS
Available                                            1
Impedance                                         0.075Ω
Power WRMS (8Ω)                            ~25W Class A / ~200W Class AB
Power WRMS (4Ω)                            ~50W Class A / ~400W Class AB
Frequency response                         +800kHz
Signal to noise ratio                         <110dB @ 1kHz
THD + noise                                     <0.01%

POWER CONSUMPTION (EACH)

• Standby <1W
• Class AB ~70W
• Class A ~135W

DIMENSIONS (EACH)

• Height 135mm including feet
• Width 435mm
• Depth 436mm / 467mm with binding posts
• Weight 36kg
• Material Aluminium for body parts and heat sinks
