Rotel

Rotel Michi X5 Series 2 Integrated Amplifier

Rotel Michi X5 Series 2 Integrated Amplifier

£8,199.00

Contact Us for purchase options:

01603 627010 info@martinshifi.co.uk

In stock

View full details

Rotel MICHI X5 Series 2 Integrated Amplifier

The Michi X5 Series 2 Integrated Amplifier is music reproduction reimagined. Thanks to a meticulous balance of innovation and critical audio engineering applied to every circuit, signal path, and electronic component, the Michi X5 Series 2 is capable of delivering an outstanding 600 Watts of Class AB output power into 4 ohms under even the most demanding conditions. Connect all your favourite music sources including Analog RCA and XLR Balanced, Moving Magnet or Moving Coil Phono, aptXTM HD Wireless Bluetooth, Coaxial and Optical.

The PC-input supports PCM (32-bit 384kHz) and Quad DSD (11.2MHz) with full MQA hardware decoding up to 24-bit 384kHz. An ESS SABRE ES9028PRO 8 Channel Digital to Analog converter is configured for stereo decoding, dedicating 4 channels each to the left and right audio signals rendering music with exceptionally accurate timing and an immersive soundstage which reveals the finest of details.

The Michi X5 Series 2 is powered by dual oversized in-house manufactured, shielded, low noise toroidal transformers feeding a bank of 4 parallel-aligned 22,000uF high-efficiency storage reservoir capacitors. Custom power supplies isolate drive current to critical analog and digital circuits delivering an ultra-quiet noise floor with exceptional control of deep bass energy while maintaining finesse and clarity of the midrange and high frequencies.

The high-resolution graphic display is configurable to show a Graphic EQ or Peak Power Meter and ensures easy setup and configuration. Custom front panel controls and the elegant Michi-series IR remote assures seamless operation from the comfort of your listening chair. Dual Platinum-plated custom Michi speaker binding posts support traditional and bi-wire installations. A full size ¼” (6.35mm) front panel headphone connection is available for private listening sessions. RS232 and Ethernet ports provide compatibility with all popular control systems.

Specifications

Maximum Power Output

600 watts/channel (4 ohms)

Continuous Power Output

350 watts/channel (8 ohms)

Total Harmonic Distortion

< 0.009%

Intermodulation Distortion
(60 Hz : 7 kHz, 4:1)

< 0.03%

Frequency Response

Phono Input
Line Level Inputs


20 Hz-20k Hz (+0 dB, -0.2 dB)
10 Hz-100k Hz (+0 dB, -0.6 dB)

Damping Factor
(20 Hz - 20kHz, 8 ohms)

350

Input Sensitivity / Impedance

Phono Input (MM)
Phono Input (MC)
Line Level Inputs (RCA)
Line Level Inputs (XLR)


5.7 mV / 47k ohms
570 uV/ 100 ohms
380 mV / 100k ohms
580 mV / 100k ohms

Input Overload

Phono Input (MM)
Phono Input (MC)
Line Level Inputs (RCA)
Line Level Inputs (XLR)


197 mV
19 mV
12.5 V
12.5 V

Preamplifier Output Level /
Impedance

Tone Controls
Bass
Treble

1 V / 470 ohms


±10 dB at 100 Hz
±10 dB at 10k Hz

Signal to Noise Ratio
(IHF “A” weighted)


Phono Input (MM/MC)

Line Level Inputs



80 dB

102dB

Channel Separation

Phono Input (MM)

Line Level Inputs


>65 dB

>65 dB

Digital Section

Frequency Response

20 Hz - 20k Hz (0 ± 0.4 dB)

Signal to Noise Ratio
(IHF “A” weighted)

102 dB

Input Sensitivity/Impedance

0 dBFs / 75 ohms

Preamplifier Output Level

1.2 V (at -20 dB Volume Position)

Coaxial/Optical Digital Signals

SPDIF LPCM (up to 192kHz 24 bit)

PC-USB

USB Audio Class 1.0
(up to 96kHz 24-bit)
USB Audio Class 2.0
(up to 384kHz 32-bit)*
*Driver installation required
DSD and DoP support
MQA and MQA Studio support
Roon Tested

Power Requirements

Europe

USA


230 V, 50 Hz

120 V, 60 Hz

Power Consumption

850 watts

Standby Power Consumption

Normal

Network Wakeup


< 0.5 watts

< 2 watts

BTU (4 ohms, 1/8 power)

2194 BTU/h

Dimensions (W x H x D)

485 x 195 x 452 mm

19" x 7 5/8" x 17 3/4"

Front Panel Height

177 mm / 7"

Weight (net)

43.8 kg, 96.56 lb

Finish

Black
