Naim
Naim CI-NAP 101
Naim CI-NAP 101
In stock
Naim CI-NAP 101 Single-Channel Power Amplifier
The CI-NAP 101 is a single-channel power amplifier from Naim's integrated solutions range — a 1U rack-mount unit designed for custom installation audio systems. It delivers 500W into 8Ω from a single channel, with simultaneous low-impedance, 70V line, and 100V line outputs. The 100V and 70V outputs make it compatible with distributed audio systems using constant-voltage speaker wiring. A stereo RCA input with mono summing at 47kΩ handles source connections; the unit also provides a stereo RCA line through-output for daisy-chaining additional amplifiers or zones.
Output Formats
Three output types are simultaneously available: a low-impedance speaker output via Euroblock connector (3Hz to 70kHz), a 70V line output via Euroblock (50Hz to 25kHz), and a 100V line output via Euroblock (50Hz to 25kHz). This flexibility means the CI-NAP 101 can drive both standard passive loudspeakers and constant-voltage distributed speaker networks from the same amplifier, making it suitable for mixed installation architectures.
Technical Specifications
| Configuration | Single-channel (mono) |
| Power output (8Ω) | 500W |
| Power output (4Ω) | 800W |
| Power output (100V) | 240W |
| Power output (70V) | 150W |
| THD+N | <0.008% |
| Analogue gain | 29dB |
| Input | Stereo RCA (mono summing, 47kΩ) |
| Line output | Stereo RCA |
| Low-impedance output | Euroblock |
| 70V output | Euroblock |
| 100V output | Euroblock |
| Frequency response (low impedance) | 3Hz to 70kHz |
| Frequency response (high impedance) | 50Hz/120Hz to 25kHz |
| Mains supply | 100V–240V universal |
| Power consumption | 100W normal use |
| Dimensions (W × H × D) | 440mm × 44.5mm × 300mm |
| Weight | 8.9kg |
Who Is It For?
The CI-NAP 101 is for custom installation projects requiring high-power mono amplification with constant-voltage output capability. The 500W output into 8Ω is well above what most zones require, making it suitable for demanding applications — large rooms, outdoor installations with long cable runs, or installations where headroom is a requirement. The 100V and 70V line outputs allow integration with commercial distributed audio speaker systems.
For multi-zone installations, the CI-NAP 108 eight-channel amplifier is a more practical solution where multiple independent zones are required in a single rack unit.
