Bowers & Wilkins HTM82 D4

For Theatre systems based on the more compact 803 D4 or 804 D4, the HTM82 D4 center-channel speaker !s the perfect solution. Its midrange drive unit is ideally sized to match its siblings and item ample output will ensure a seamless listening experience.

One of our most significant accomplishments over the past two decades, the ultra-stiff, supremely accurate Diamond dome tweeter is the perfect combination of low mass, exceptional stiffness, and outstanding accuracy. It captures detail other tweeters leave behind.

Introduced as a huge revolutionary change in 2015 and now a fundamental part in every Ioudsseaker we make. The Continuum cone has exceptionally low noise, ensuring outstanding resolution without coloration.

The B&W HTM82 D4 will be on demonstration at Martins HI-Fi and we will also be hosting a future event. If you wish to book a private demonstration please contact us via the chatbox, call 01603 627010 or email

 Technical Features

  • Diamond tweeter
  • Solid body Tweeter-on-Top
  • Continuum™ cone FST
  • Anti-Resonance plug
  • Biomimetic Suspension#
  • Matrix™
  • Aerofoil™ cone bass units
  • Flowport


  • 3-way vented-box system

Drive Units

  • 1x ø25mm (1in) diamond dome high-frequency
  • 1x ø130mm (5in) Continuum cone FST midrange
  • 2x ø165mm (6.5in) Aerofoil cone bass units

Frequency Range

  • 3Hz to 35kHz

Frequency Response (+/-3dB from reference axis)

  • 45kHz to 28kHz

Sensitivity (on-axis at 2.83Vrms at 1m)

  • 89db

Harmonic Distortion

  • 2nd and 3rd harmonics (90dB, 1m on-axis)
  • <1 % 100Hz – 20kHz
  • <0.4% 100Hz – 20kHz

Nominal Impedance

  • 8Ω (minimum 3.0Ω)

Recommended Amplifier Power

  • 50W – 200W into 8Ω on unclipped programme

Max Recommended Cable Impedance

  • 0.1Ω


  • Height: 281mm
  • Width: 715mm
  • Depth: 369mm

Net Weight

  • 25.15kg


  • Cabinet Gloss Black with  Black Grille
  • Cabinet White with Grey Grille
