Bowers & Wilkins HTM81 D4
Bowers & Wilkins HTM81 D4
Bowers & Wilkins HTM81 D4
Our largest center-channel speaker is designed to be the perfect partner for the 801 D4 or 802 D4. Small wonder, then, that it’s such a powerful performer, with a sound that perfectly matches the quality of its illustrious stablemates.
Inside HTM81 D4, B&W uses a stiff, aluminum enclosure designed to maximise the performance of the midrange drive unit. It Provides a controlled location point for the midrange decoupling and prevents unwanted air leakage into the surrounding cabinet.
B&W Aerofoil bass cone technology remains an outstanding solution to the conundrum of combining low mass and high stiffness., thanks to its carbon-fiber skin and variable-profile foam core. Now, we have added the foam Anti-Resonance PIug for lower distortion and even cleaner bass.
The B&W HTM81 D4 will be on demonstration at Martins HI-Fi and we will also be hosting a future event. If you wish to book a private demonstration please contact us via the chatbox, call 01603 627010 or email info@martinshifi.co.uk
Technical Features
- Diamond tweeter
- Solid body Tweeter-on-Top
- Continuum™ cone FST
- Anti-Resonance plug
- Biomimetic Suspension#
- Matrix™
- Aerofoil™ cone bass units
- Flowport
Description
- 3-way vented-box system
Drive Units
- 1x ø25mm (1in) diamond dome high-frequency
- 1x ø150mm (6in) Continuum cone FST midrange
- 2x ø200mm (8in) Aerofoil cone bass units
Frequency Range
- 20Hz to 35kHz
Frequency Response (+/-3dB from reference axis)
- 28kHz to 28kHz
Sensitivity (on-axis at 2.83Vrms at 1m)
- 90db
Harmonic Distortion
- 2nd and 3rd harmonics (90dB, 1m on-axis)
- <1 % 80Hz – 20kHz
- <0.3% 100Hz – 20kHz
Nominal Impedance
- 8Ω (minimum 3.0Ω)
Recommended Amplifier Power
- 50W – 500W into 8Ω on unclipped programme
Max Recommended Cable Impedance
- 0.1Ω
Dimensions
- Height: 334mm
- Width: 847mm
- Depth: 371mm
Net Weight
- 32.20kg
Finishes
- Cabinet Gloss Black with Black Grille
- Cabinet White with Grey Grille
